The Hikvision DS-QAE0120G1R is a 20W analog cabinet speaker designed for professional public address, voice announcement and background music applications. It features a 5.25-inch full-frequency speaker and supports both 70V and 100V constant-voltage systems, with selectable power levels of 5W, 10W, 15W and 20W. It also supports 8Ω constant-impedance input for flexible system integration. The speaker delivers clear, balanced audio with a 90 dB ±3 dB sensitivity, 103 dB maximum SPL and a 130 Hz–17.5 kHz frequency response. Its U-shaped mounting bracket allows the installation angle to be adjusted, while supporting both horizontal and vertical installation. The durable plastic cabinet and metal bracket make it suitable for a variety of commercial and public-address environments.
